+## Transition 过渡动画
|
|
|
+> **组件名:uni-transition**
|
|
|
+> 代码块: `uTransition`
|
|
|
+
|
|
|
+
|
|
|
+元素过渡动画
|
|
|
+
|
|
|
+> **注意事项**
|
|
|
+> 为了避免错误使用,给大家带来不好的开发体验,请在使用组件前仔细阅读下面的注意事项,可以帮你避免一些错误。
|
|
|
+> - 组件需要依赖 `sass` 插件 ,请自行手动安装
|
|
|
+> - rotate 旋转动画不需要填写 deg 单位,在小程序上填写单位动画不会执行
|
|
|
+> - NVUE 下修改宽高动画,不能定位到中心点
|
|
|
+> - 百度小程序下修改宽高 ,可能会影响其他动画,需注意
|
|
|
+> - nvue 不支持 costom-class , 请使用 styles
|
|
|
+> - 如使用过程中有任何问题,或者您对uni-ui有一些好的建议,欢迎加入 uni-ui 交流群:871950839
|
|
|
+
|
|
|
+
|
|
|
+### 安装方式
|
|
|
+
|
|
|
+本组件符合[easycom](https://uniapp.dcloud.io/collocation/pages?id=easycom)规范,`HBuilderX 2.5.5`起,只需将本组件导入项目,在页面`template`中即可直接使用,无需在页面中`import`和注册`components`。
|
|
|
+
|
|
|
+如需通过`npm`方式使用`uni-ui`组件,另见文档:[https://ext.dcloud.net.cn/plugin?id=55](https://ext.dcloud.net.cn/plugin?id=55)
|
|
|
+
|
|
|
+### 基本用法
|
|
|
+
|
|
|
+在 ``template`` 中使用组件
|
|
|
+
|
|
|
+```html
|
|
|
+<template>
|
|
|
+ <view>
|
|
|
+ <button type="primary" @click="open">fade</button>
|
|
|
+ <uni-transition mode-class="fade" :styles="{'width':'100px','height':'100px','backgroundColor':'red'}" :show="show" @change="change" />
|
|
|
+ </view>
|
|
|
+</template>
|
|
|
+
|
|
|
+<script>
|
|
|
+export default {
|
|
|
+ data() {
|
|
|
+ return {
|
|
|
+ show: false,
|
|
|
+ }
|
|
|
+ },
|
|
|
+ onLoad() {},
|
|
|
+ methods: {
|
|
|
+ open(mode) {
|
|
|
+ this.show = !this.show
|
|
|
+ },
|
|
|
+ change() {
|
|
|
+ console.log('触发动画')
|
|
|
+ }
|
|
|
+ }
|
|
|
+}
|
|
|
+</script>
|
|
|
+```
|
|
|
+
|
|
|
+### 样式覆盖
|
|
|
+
|
|
|
+**注意:`nvue` 不支持 `custom-class` 属性 ,需要使用 `styles` 属性进行兼容**
|
|
|
+
|
|
|
+使用 `custom-class` 属性绑定样式,可以自定义 `uni-transition` 的样式
|
|
|
+
|
|
|
+```html
|
|
|
+<template>
|
|
|
+ <view class="content">
|
|
|
+ <uni-transition custom-class="custom-transition" mode-class="fade" :duration="0" :show="true" />
|
|
|
+ </view>
|
|
|
+</template>
|
|
|
+
|
|
|
+<style>
|
|
|
+/* 常规样式覆盖 */
|
|
|
+.content >>> .custom-transition {
|
|
|
+ width:100px;
|
|
|
+ height:100px;
|
|
|
+ background-color:red;
|
|
|
+}
|
|
|
+</style>
|
|
|
+<style lang="scss">
|
|
|
+/* 如果使用 scss 需要使用 /deep/ */
|
|
|
+.content /deep/ .custom-transition {
|
|
|
+ width:100px;
|
|
|
+ height:100px;
|
|
|
+ background-color:red;
|
|
|
+}
|
|
|
+</style>
|
|
|
+```
|
|
|
+
|
|
|
+
|
|
|
+如果使用 `styles` 注意带’-‘连接符的属性需要使用小驼峰写法如:`backgroundColor:red`
|
|
|
+
|
|
|
+```html
|
|
|
+<template>
|
|
|
+ <view class="content">
|
|
|
+ <uni-transition :styles="styles" mode-class="fade" :duration="0" :show="true" />
|
|
|
+ </view>
|
|
|
+</template>
|
|
|
+<script>
|
|
|
+export default {
|
|
|
+ data() {
|
|
|
+ return {
|
|
|
+ styles:{
|
|
|
+ 'width':'100px',
|
|
|
+ 'height':'100px',
|
|
|
+ 'backgroundColor':'red'
|
|
|
+ }
|
|
|
+ }
|
|
|
+ }
|
|
|
+}
|
|
|
+</script>
|
|
|
+```
|
|
|
+
|
|
|
+### 自定义动画
|
|
|
+当内置动画类型不能满足需求的时候 ,可以使用 `step()` 和 `run()` 自定义动画,入参以及具体用法参考下方属性说明
|
|
|
+
|
|
|
+`init()` 方法可以覆盖默认配置
|
|
|
+
|
|
|
+
|
|
|
+```html
|
|
|
+<template>
|
|
|
+ <view>
|
|
|
+ <button type="primary" @click="run">执行动画</button>
|
|
|
+ <uni-transition ref="ani" :styles="{'width':'100px','height':'100px','backgroundColor':'red'}" :show="show" />
|
|
|
+ </view>
|
|
|
+</template>
|
|
|
+
|
|
|
+<script>
|
|
|
+export default {
|
|
|
+ data() {
|
|
|
+ return {
|
|
|
+ show: true,
|
|
|
+ }
|
|
|
+ },
|
|
|
+ onReady() {
|
|
|
+ this.$refs.ani.init({
|
|
|
+ duration: 1000,
|
|
|
+ timingFunction: 'linear',
|
|
|
+ transformOrigin: '50% 50%',
|
|
|
+ delay: 500
|
|
|
+ })
|
|
|
+ },
|
|
|
+ methods: {
|
|
|
+ run() {
|
|
|
+ // 同时右平移到 100px,旋转 360 读
|
|
|
+ this.$refs.ani.step({
|
|
|
+ translateX: '100px',
|
|
|
+ rotate: '360'
|
|
|
+ })
|
|
|
+ // 上面的动画执行完成后,等待200毫秒平移到 0px,旋转到 0 读
|
|
|
+ this.$refs.ani.step({
|
|
|
+ translateX: '0px',
|
|
|
+ rotate: '0'
|
|
|
+ },
|
|
|
+ {
|
|
|
+ timingFunction: 'ease-in',
|
|
|
+ duration: 200
|
|
|
+ })
|
|
|
+ // 开始执行动画
|
|
|
+ this.$refs.ani.run(()=>{
|
|
|
+ console.log('动画支持完毕')
|
|
|
+ })
|
|
|
+ }
|
|
|
+ }
|
|
|
+}
|
|
|
+</script>
|
|
|
+```
|
|
|
+
|
|
|
+
|
|
|
+## API
|
|
|
+
|
|
|
+### Transition Props
|
|
|
+
|
|
|
+|属性名 |类型 |默认值 |说明 |
|
|
|
+|:-: |:-: |:-: |:-:|
|
|
|
+|show |Boolean|false |控制组件显示或隐藏 |
|
|
|
+|mode-class |Array/String |- |内置过渡动画类型 |
|
|
|
+|custom-class |String |- |自定义类名 |
|
|
|
+|duration |Number |300 |过渡动画持续时间 |
|
|
|
+|styles |Object |- |组件样式,同 css 样式,注意带’-‘连接符的属性需要使用小驼峰写法如:`backgroundColor:red` |
|
|
|
+
|
|
|
+#### mode-class 内置过渡动画类型说明
|
|
|
+**格式为** :`'fade'` 或者 `['fade','slide-top']`
|
|
|
+
|
|
|
+|属性名 |说明 |
|
|
|
+|:-: |:-: |
|
|
|
+|fade |渐隐渐出过渡 |
|
|
|
+|slide-top |由上至下过渡 |
|
|
|
+|slide-right |由右至左过渡 |
|
|
|
+|slide-bottom |由下至上过渡 |
|
|
|
+|slide-left |由左至右过渡 |
|
|
|
+|zoom-in |由小到大过渡 |
|
|
|
+|zoom-out |由大到小过渡 |
|
|
|
+
|
|
|
+**注意**
|
|
|
+
|
|
|
+组合使用时,同一种类型相反的过渡动画如(slide-top、slide-bottom)同时使用时,只有最后一个生效
|
|
|
+
|
|
|
+### Transition Events
|
|
|
+
|
|
|
+|事件名 |说明 |返回值 |
|
|
|
+|:-: |:-: |:-: |
|
|
|
+|click |点击组件触发 |- |
|
|
|
+|change |过渡动画结束时触发 | e = {detail:true} |
|
|
|
+
|
|
|
+### Transition Methons
|
|
|
+
|
|
|
+|方法名|说明|参数|
|
|
|
+|:-:|:-:|:-:|
|
|
|
+|init()|手动初始化配置|Function(OBJECT:config)|
|
|
|
+|step()|动画队列|Function(OBJECT:type,OBJECT:config)|
|
|
|
+|run()|执行动画|Function(FUNCTION:callback) |
|
|
|
+
|
|
|
+### init(OBJECT:config)
|
|
|
+**通过 ref 调用方法**
|
|
|
+
|
|
|
+手动设置动画配置,需要在页面渲染完毕后调用
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.init({
|
|
|
+ duration: 1000,
|
|
|
+ timingFunction:'ease',
|
|
|
+ delay:500,
|
|
|
+ transformOrigin:'left center'
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+### step(OBJECT:type,OBJECT:config) 动画队列
|
|
|
+**通过 ref 调用方法**
|
|
|
+
|
|
|
+调用 `step()` 来表示一组动画完成,`step` 第一个参数可以传入任意多个动画方法,一组动画中的所有动画会同时开始,一组动画完成后才会进行下一组动画。`step` 第二个参数可以传入一个跟 `uni.createAnimation()` 一样的配置参数用于指定当前组动画的配置。
|
|
|
+
|
|
|
+Tips
|
|
|
+- 第一个参数支持的动画参考下面的 `支持的动画`
|
|
|
+- 第二个参数参考下面的 `动画配置`,可省略,如果省略继承`init`的配置
|
|
|
+
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ translateX: '100px'
|
|
|
+},{
|
|
|
+ duration: 1000,
|
|
|
+ timingFunction:'ease',
|
|
|
+ delay:500,
|
|
|
+ transformOrigin:'left center'
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+### run(FUNCTION:callback) 执行动画
|
|
|
+**通过 ref 调用方法**
|
|
|
+
|
|
|
+在执行 `step()` 后,需要调用 `run()` 来运行动画 ,否则动画会一直等待
|
|
|
+
|
|
|
+`run()` 方法可以传入一个 `callback` 函数 ,会在所有动画执行完毕后回调
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ translateX: '100px'
|
|
|
+})
|
|
|
+this.$refs.ani.run(()=>{
|
|
|
+ console.log('动画执行完毕')
|
|
|
+})
|
|
|
+
|
|
|
+```
|
|
|
+
|
|
|
+### 动画配置
|
|
|
+动画配置 , `init()` 与 `step()` 第二个参数配置相同 ,如果配置`step() `第二个参数,将会覆盖 `init()` 的配置
|
|
|
+
|
|
|
+|属性名|值|必填|默认值|说明|平台差异|
|
|
|
+|:-:|:-:|:-:|:-:|:-:|:-:|
|
|
|
+|duration|Number|否|400|动画持续时间,单位ms|-|
|
|
|
+|timingFunction|String|否|"linear"|定义动画的效果|-|
|
|
|
+|delay|Number|否|0|动画延迟时间,单位 ms|-|
|
|
|
+|needLayout|Boolean|否|false |动画执行是否影响布局|仅 nvue 支持|
|
|
|
+|transformOrigin|String |否|"center center"|设置 [transform-origin](https://developer.mozilla.org/en-US/docs/Web/CSS/transform-origin)|-|
|
|
|
+
|
|
|
+
|
|
|
+### timingFunction 属性说明
|
|
|
+
|
|
|
+|值|说明|平台差异|
|
|
|
+|:-:|:-:|:-:|
|
|
|
+|linear|动画从头到尾的速度是相同的|-|
|
|
|
+|ease|动画以低速开始,然后加快,在结束前变慢|-|
|
|
|
+|ease-in| 动画以低速开始|-|
|
|
|
+|ease-in-out| 动画以低速开始和结束|-|
|
|
|
+|ease-out|动画以低速结束|-|
|
|
|
+|step-start|动画第一帧就跳至结束状态直到结束|nvue不支持|
|
|
|
+|step-end|动画一直保持开始状态,最后一帧跳到结束状态|nvue不支持|
|
|
|
+
|
|
|
+```javascript
|
|
|
+// init 配置
|
|
|
+this.$refs.ani.init({
|
|
|
+ duration: 1000,
|
|
|
+ timingFunction:'ease',
|
|
|
+ delay:500,
|
|
|
+ transformOrigin:'left center'
|
|
|
+})
|
|
|
+// step 配置
|
|
|
+this.$refs.ani.step({
|
|
|
+ translateX: '100px'
|
|
|
+},{
|
|
|
+ duration: 1000,
|
|
|
+ timingFunction:'ease',
|
|
|
+ delay:500,
|
|
|
+ transformOrigin:'left center'
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+### 支持的动画
|
|
|
+动画方法
|
|
|
+
|
|
|
+如果同一个动画方法有多个值,多个值使用数组分隔
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ width:'100px',
|
|
|
+ scale: [1.2,0.8],
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+**样式:**
|
|
|
+
|
|
|
+|属性名|值|说明|平台差异|
|
|
|
+|:-:|:-:|:-:|:-:|
|
|
|
+|opacity|value|透明度,参数范围 0~1|-|
|
|
|
+|backgroundColor|color|颜色值|-|
|
|
|
+|width|length|长度值,如果传入 Number 则默认使用 px,可传入其他自定义单位的长度值|-|
|
|
|
+|height|length|长度值,如果传入 Number 则默认使用 px,可传入其他自定义单位的长度值|-|
|
|
|
+|top|length|长度值,如果传入 Number 则默认使用 px,可传入其他自定义单位的长度值|nvue 不支持|
|
|
|
+|left|length|长度值,如果传入 Number 则默认使用 px,可传入其他自定义单位的长度值|nvue 不支持|
|
|
|
+|bottom|length|长度值,如果传入 Number 则默认使用 px,可传入其他自定义单位的长度值|nvue 不支持|
|
|
|
+|right|length|长度值,如果传入 Number 则默认使用 px,可传入其他自定义单位的长度值|nvue 不支持|
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ opacity: 1,
|
|
|
+ backgroundColor: '#ff5a5f',
|
|
|
+ widht:'100px',
|
|
|
+ height:'50rpx',
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+**旋转:**
|
|
|
+
|
|
|
+旋转属性的值不需要填写单位
|
|
|
+
|
|
|
+|属性名|值|说明|平台差异 |
|
|
|
+|:-:|:-:|:-:|:-:|
|
|
|
+|rotate|deg|deg的范围-180~180,从原点顺时针旋转一个deg角度 |-|
|
|
|
+|rotateX|deg|deg的范围-180~180,在X轴旋转一个deg角度 |-|
|
|
|
+|rotateY|deg|deg的范围-180~180,在Y轴旋转一个deg角度 |-|
|
|
|
+|rotateZ|deg|deg的范围-180~180,在Z轴旋转一个deg角度 |nvue不支持|
|
|
|
+|rotate3d|x,y,z,deg| 同 [transform-function rotate3d](https://developer.mozilla.org/en-US/docs/Web/CSS/transform-function/rotate3d()) |nvue不支持|
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ rotateX: 45,
|
|
|
+ rotateY: 45
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+**缩放:**
|
|
|
+
|
|
|
+|属性名|值|说明|平台差异|
|
|
|
+|:-:|:-:|:-: |:-:|
|
|
|
+|scale|sx,[sy]|一个参数时,表示在X轴、Y轴同时缩放sx倍数;两个参数时表示在X轴缩放sx倍数,在Y轴缩放sy倍数|-|
|
|
|
+|scaleX|sx|在X轴缩放sx倍数|-|
|
|
|
+|scaleY|sy|在Y轴缩放sy倍数|-|
|
|
|
+|scaleZ|sz|在Z轴缩放sy倍数|nvue不支持|
|
|
|
+|scale3d|sx,sy,sz|在X轴缩放sx倍数,在Y轴缩放sy倍数,在Z轴缩放sz倍数|nvue不支持|
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ scale: [1.2,0.8]
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+**偏移:**
|
|
|
+
|
|
|
+|属性名|值|说明|平台差异|
|
|
|
+|:-:|:-:|:-:|:-:|
|
|
|
+|translate|tx,[ty]|一个参数时,表示在X轴偏移tx,单位px;两个参数时,表示在X轴偏移tx,在Y轴偏移ty,单位px。|-|
|
|
|
+|translateX|tx| 在X轴偏移tx,单位px|-|
|
|
|
+|translateY|ty| 在Y轴偏移tx,单位px|-|
|
|
|
+|translateZ|tz| 在Z轴偏移tx,单位px|nvue不支持|
|
|
|
+|translate3d|tx,ty,tz| 在X轴偏移tx,在Y轴偏移ty,在Z轴偏移tz,单位px|nvue不支持|
|
|
|
+
|
|
|
+```javascript
|
|
|
+this.$refs.ani.step({
|
|
|
+ translateX: '100px'
|
|
|
+})
|
|
|
+```
|
|
|
+
|
|
|
+
|
|
|
+
|
|
|
+## 组件示例
|
|
|
+
|
|
|
+点击查看:[https://hellouniapp.dcloud.net.cn/pages/extUI/transition/transition](https://hellouniapp.dcloud.net.cn/pages/extUI/transition/transition)
|
